Vision 1.5 Ton Split Type Inverter AC -VSN-18K-INV32 4D Ultra

Vision 1.5 Ton Split Type Inverter AC -VSN-18K-INV32 4D Ultra is a 1.5 ton wall-mounted split air conditioner rated at 18000 BTU/Hr. Its inverter compressor slows down rather than switching off once the room reaches the set temperature, so cooling stays even and running cost is easier to manage through a long afternoon.

Rated cooling output is 5275 W across a 1200~5400 W working range, letting the unit match its capacity to the load. Power input is 1758W at 7.8A and 50 Hz, and the wide 187~265V voltage range keeps this Vision 1.5 Ton Inverter AC running through supply swings.

Inside is a HIGHLY rotary compressor with R32 refrigerant. The condenser uses inner groove copper tube (7mm) finished with an Al golden fin coating for corrosion protection. Indoor noise measures 46 dB and outdoor noise 55 dB. The Vision VSN-18K-INV32 4D Ultra also brings 3D air flow, a hidden display, a dust filter, a sleep mode timer and a remote control, while Wi-Fi control is not available.

For fitting, the indoor unit measures 920×306×195 mm at 10.5 kg net and the outdoor unit 853×349×602 mm at 27.5 kg net. Buyers weighing up a Vision 18000 BTU Inverter AC should compare BTU rating, refrigerant type, coil material and noise figures alongside room size.

Highlights

• 1.5 ton cooling capacity, 18000 BTU/Hr
• Inverter split type air conditioner
• 5275 W cooling output with a 1200~5400 W range
• 1758W power input, 7.8A current, 50 Hz
• 187~265V wide voltage range
• HIGHLY rotary compressor with R32 refrigerant
• Inner groove copper tube (7mm) condenser
• Al golden fin
• 46 dB indoor noise, 55 dB outdoor noise
• Hidden display, dust filter and sleep mode timer
• 3D air flow with remote control
• 10.5 kg indoor net weight, 27.5 kg outdoor net weight

Warranty Information

• Compressor: 12 Years
• Spare Parts / PCB: 4 Years
• After Sales Service: 4 Years
• Cleaning Service: 1 Year

Important Usage Instructions

• Have both units fitted by a trained technician and leave clear space around the outdoor unit for airflow.
• Set the temperature near 24-26°C and let the inverter compressor hold it instead of switching the unit on and off repeatedly.
• Wash the dust filter every two to three weeks so the 18000 BTU/Hr capacity is not choked.
• Keep windows and doors closed while cooling and draw curtains against direct sunlight.
• Turn the breaker off during storms or long absences, and wait a few minutes before restarting after a shutdown.

ব্যবহার ও রক্ষণাবেক্ষণ নির্দেশনা

• Indoor ও outdoor দুটি unit দক্ষ technician দিয়ে বসান এবং outdoor unit-এর চারপাশে বাতাস চলাচলের জায়গা রাখুন।
• Temperature 24-26°C-এ রাখুন; বারবার বন্ধ-চালু না করে inverter compressor-কে কাজ করতে দিন।
• প্রতি দুই-তিন সপ্তাহে dust filter ধুয়ে নিন, না হলে 18000 BTU/Hr ক্ষমতা কমে যায়।
• এসি চলার সময় দরজা-জানালা বন্ধ রাখুন এবং সরাসরি রোদ আটকাতে পর্দা টেনে দিন।
• ঝড়-বৃষ্টি বা দীর্ঘ অনুপস্থিতিতে breaker বন্ধ রাখুন; বন্ধ করার কয়েক মিনিট পর আবার চালু করুন।

Vision VSN-18K-INV32 4D Ultra কোথায় পাবেন?

Official warranty-সহ Vision VSN-18K-INV32 1.5 Ton Inverter AC পাবেন LM Electronics-এ। LM Electronics Vision-এর Official Dealer। সকল Air Conditioner দেখতে ক্লিক করুন।
